6. SOFTWARE CONFIGURATION

6.1 INSTALLATION PROCESS

There is no installation process. In fact, UTrack is a program already
installed in the UNet and it runs with any browser (Google Chrome,
Mozilla Firefox, Microsoft Edge,...).
The UTrack address is, by default:
http://192.168.1.100:4000
In order to make the NexU configuration, it is highly recommendable to
do it with a particular PC the IPv4 network address range has to be
192.168.1.101

6.1.1 HOW TO CHANGE THE IPV4 ADDRESS FOR A LOCAL NETWORK

As we have already said, configuration can be made in a local PC. His PC has
to be in the same range as the one of the UNet. This is the procedure to do it.
Windows 10
Press the Windows Icon and go to the configuration menu:
Go to Network and Internet – Status – Network and Sharing Center
Click on Ethernet 2 and other window will pop up.
Now Click on Internet Protocol Version 4 (TCP/IPv4).
SAMOA Industrial, S.A. · Pol. Ind. Porceyo, I-14 · Camino del Fontán, 831 · 33392 - Gijón - Spain · Tel.: +34 985 381 488 · www.samoaindustrial.com
Once the UTrack configuration is made, the last of the steps will be to
change the IPv4 network address according to the customer network.
NOTE: The customer has to give us a fixed IPv4 network address in order
to connect the UTrack. This action will allow the customer to access the
UTrack from any PC / laptop / mobile phone of the customer facilities (if
there are no restrictions from IT department).
The first thing that has to be made is connecting the Ethernet wire from
the UNet to the PC. Then a local network will be automatically created
(in this example, the name for the network is Ethernet 2).
You will find the available networks. In this example, the network is
Ethernet 2.
Click on Properties.
Choose Use the following IP address and set 192.168.1.101 (the Subnet
mask will be set automatically to 255.255.255.0 If not, please set it)
Then press OK and once you open the browser again and insert
http://192.168.1.100:4000,
NexU software.
you will be able to access
