6. SOFTWARE CONFIGURATION

6.2.8 NETWORK

In this menu you can set all the data for linking NexU to the
customer's network.
If you want to use the UNet with a DHCP configuration, tick the option.
If not, which is the recommended option, then the requested data are:
• IP Address
• Mask
• Gateway
• DNS (just in case the user wants to send emails when an alarm
is reached).

7. MANAGER

Once you open the IP address designed by the customer, you will get the
main screen.
You have to go to and then insert user and password.
At the left lower part of the screen you will see the number of transaction
in progress and details of the transactions. (In this case there is one
transaction in progress, the job order is 1, the delivered liquid is 0W30
and it has been made by Samoa, Admin).
The upper bar shows six different submenus:
We will go through all of them to show all the possibilities.

7.1 HOME

In the upper part you will see a rolling screen in which the situation of
the tanks is available.
In that upper right part of that sub-window you can see
it, that sub-windows will turn and it will show more data about that
particular tank.
Below those sub-windows, you will find three more sub-windows. Left
and right ones indicate the percentage of total fluid consumption since
first UTrack installation. The one in the middle indicates the product
variation referred to the previous month.
36
838 861 R. 11/21
SAMOA Industrial, S.A. · Pol. Ind. Porceyo, I-14 · Camino del Fontán, 831 · 33392 - Gijón - Spain · Tel.: +34 985 381 488 · www.samoaindustrial.com
IMPORTANT: Once you have set the previous parameters of the
network, the 192.168.1.100:4000 address link is broken. You
would need to get into the customer network and access to
UTrack by inserting the new IP address in the browser.
. If you press
