Ref. Code
Réf. Code
Rif. codice
71 919062
91906200
72 921551
73 921544
92154400
74 917042
91704200
75 495250
49525000
76 495079
49507900
77 495253
49525300
78 495019
49501900
79 923552
92355200
80 920929
21030950
81 922527
21030350
82 917239
83 919216
84 495090
85 495082/M
86 495085/M
87 913390
91341300
88 910121
91012100
SCREW M10X20
VIS STEI M10X20
VITE STEI M10X20
KEY 8x7x70
LANGUETTE 8x7x70
LINGUETTA 8x7x70
KEY 8x7x35
LANGUETTE 8x7x35
LINGUETTA 8x7x35
GALVANISED SCREW TEIF M10X75
VIS TEIF M10X75 ZINGUEE
VITE TEIF M10X75 ZINCATA
BOWL PROTECTION GRID
GRILLE PROTECTION CUVE
GRIGLIA PROTEZIONE VASCA
LEVER FOR GAS SPRING
LEVIER POUR RESSORT A GAZ
LEVA PER MOLLA A GAS
GRID FULCRUM PIN
PIVOT POINT D'APPUI GRILLE
PERNO FULCRO GRIGLIA
CAM FOR GRID PROTECTION MICROSWITCH
CAME POUR MICRO PROTECTION GRILLE
CAMMA PER MICRO PROTEZIONE GRIGLIA
GAS SPRING 600N
RESSORT A GAZ 600N
MOLLA A GAS 600N
SELF-LOCKING NUT M8
ECROU A AUTOSERRAGE M8
DADO AUTOBLOCCANTE M8
SPRING PIN 5X30
CHEVILLE ELASTIQUE 5X30
SPINA ELASTICA 5X30
GALVANISED SCREW TEIF M8x40
VIS TEIF M8x40 ZINGUEE
VITE TEIF M8x40 ZINCATA
SELF-LOCKING GRUB SCREW M6x8
GOUPILLE M6x8 A AUTOSERRAGE
GRANO M6x8 AUTOBLOCCANTE
ROLLER PROTECTION CASING
CARTER PROTECTION ROULEAUX
CARTER PROTEZIONE RULLI
LEFT BOWL ROLLER SUPPORT (MACHINE VIEWED FROM FRONT)
SUPPORT POUSSE CUVE GAUCHE EN REGARDANT LA MACHINE DE FACE
SUPPORTO SPINGIVASCA SINISTRO GUARDANDO LA MACCHINA DA
DAVANTI
RIGHT BOWL ROLLER SUPPORT (MACHINE VIEWED FROM FRONT)
SUPPORT POUSSE CUVE DROIT EN REGARDANT LA MACHINE DE FACE
SUPPORTO SPINGIVASCA DESTRA GUARDANDO LA MACCHINA DA DAVANTI
ROLLER DIAMETER 70x70
ROULEAU DIAMETRE 70x70
RULLO DIAMETRO 70x70
BEARING 6202-2RS 15x35x11
ROULEMENT 6202-2RS 15x35x11
CUSCINETTO 6202-2RS 15x35x11
Description
Description
descrizione
Q.ty
Q.té
Q.tà
2
1
1
1
1
1
1
1
1
2
3
1
1
2
1
1
2
4
