Ref. Code
Réf. Code
Rif. codice
1 495252/M
49525200
2 495268/M
49526800
3 913394
91339400
4 913383
91338800
5 913387
6 917246
7 920612
8 920562
04019450
9 917558
91755800
10 916508
11 920640
12 495265
13 212141
21214101
14 495251
15 412222
16 412130
17 414354
41435400
18 917600
91760000
19 920563
PAINTED LOWER CASING
CARTER INFERIEUR VERNI
CARTER SOTTOSTANTE VERNICIATO
PAINTED LOWER WHEEL SUPPORT PLATE
PLAQUE INFERIEURE SUPPORT ROUE VERNI
PIASTRA INFERIORE SUPPORTO RUOTA VERNICIATA
JOINTED FOOT M20x100 DIAMETER 100
PIED ARTICULE M20x100 DIAMETRE 100
PIEDINO SNODATO M20x100 DIAMETRO 100
REVOLVING WHEEL H=140mm CAPACITY=400KG
ROUE PIVOTANTE H=140mm PORTEE=400KG
RUOTA GIREVOLE H=140mm PORTATA=400KG
FIXED WHEEL H=140mm CAPACITY=400KG
ROUE FIXE H=140mm PORTEE=400KG
RUOTA FISSA H=140mm PORTATA=400KG
GALVANISED SCREW TEIF M8X20
VIS TEIF M8X20 ZINGUEE
VITE TEIF M8X20 ZINCATA
GALVANISED PLAIN WASHER d8
RONDELLE PLATE d8 ZINGUEE
RONDELLA PIANA d8 ZINCATA
GALVANISED SERRATED WASHER d8.4X14
RONDELLE DENTEE d8.4X14 ZINGUEE
RONDELLA DENTATA d8.4X14 ZINCATA
GALVANISED SCREW TCEI M8x20
VIS TCEI M8x20 ZINGUEE
VITE TCEI M8x20 ZINCATA
STAINLESS STEEL SCREW TEIF M8x16
VIS TEIF M8x16 INOX
VITE TEIF M8x16 INOX
STAINLESS STEEL PLAIN WASHER 8.4x17x1.6
RONDELLE PLATE 8.4x17x1.6 INOX
RONDELLA PIANA 8.4x17x1.6 INOX
FLOUR GUARD
PLAQUE ANTI-ECLABOUSSURES
PARAFARINA
SPIRAL
SPIRALE
SPIRALE
COLUMN
BARRE
PIANTONE
COLUMN SHIM
EPAISSEUR BARRE
SPESSORE PIANTONE
BEARINGS LOWER PROTECTION
PROTECTION INFERIEURE ROULEMENTS
PROTEZIONE INFERIORE CUSCINETTI
SHIM FOR SPIRAL
EPAISSEUR POUR SPIRALE
SPESSORE PER SPIRALE
STAINLESS STEEL SCREW TCEI M16X55
VIS TCEI M16X55 INOX
VITE TCEI M16X55 INOX
STAINLESS STEEL SERRATED WASHER d8.4X14
RONDELLE DENTEE d8.4X14 INOX
RONDELLA DENTATA d8.4X14 INOX
DEPUIS NUMERO DE SERIE 02.01458
Description
Description
descrizione
Q.ty
Q.té
Q.tà
1
1
2
1
2
12
45
36
8
10
16
1
1
1
2
1
2
3
10
185
