ULTRAFLEX
2 SYSTEM USE
2.1
Control panel
USER MENU
USER
STEERING MODE
From the STEERING MODE menu it is possible to select one of two steering modes: AUTOCRUISE and AUTO-
SPORT. The modes allow the user to choose between two steering response settings, and the steering wheel
turns have been set by the dealer and cannot be changed by the user. Steering wheel hardness can be changed
independently as described in the menus below.
LOW RPM STEERING
FRICTION
By means of this parameter, it is possible to set the resistance of the steering wheel when the engine is at low
idle (0 to 10). The value 0 corresponds to the minimum resistance; the value 10 to the maximum resistance.
HIGH RPM STEERING
FRICTION
By means of this parameter, it is possible to set the resistance of the steering wheel when the engine is at high
idle (0 to 10). The value 0 corresponds to the minimum resistance; the value 10 to the maximum resistance.
NOTICE
The system will vary the hardness of the steering wheel gradually between set values as rpm changes.
NOTICE
LOW RPM STEERING FRICTION and HIGH RPM STEERING FRICTION values are automatically stored by the
system for the two modes 'Autocruise' and 'Autsport' respectively.
DETENT AT MID STROKE
By means of this parameter,
angle.
This function can help the user to quickly identify the moment when the engines are in a central position.
ANCHOR RESPONSIVENESS
Through the ANCHOR Responsiveness parameter, it is possible to set an anchor efficiency value, between 0 and 10
(0 minimum efficiency value, 10 maximum efficiency value), which adjusts the maximum deviation from the GPS
position and compass angle at the time the anchor is inserted. This value should be set according to the environ-
mental conditions you are in (e.g. wind strength, sea state, etc.).
CAUTION
A high value of this parameter could put more stress on the motor inverters.
STEERING MODE
LOW RPM STEERING
FRICTION
HIGH RPM STEERING
FRICTION
DETENT AT MID STROKE
ANCHOR RESPONSIVENESS
it is possible to activate a haptic feedback of the steering wheel at the 0° steering
User manual
AUTOCRUISE
AUTOSPORT
[0-10]
[0-10]
[ON-OFF]
[0 - 10]
page 9
INTEGRA SYSTEM
of 119
