ULTRAFLEX
1 SYSTEM DESCRIPTION
1.1
System description and features
INTEGRA is a steer-by-wire steering system which combines traditional hydraulic components with electronic
components checked by a specific data network
INTEGRA can be considered as an extremely safe and reliable system thanks to its communication system
equipped with sensors, systems of self-checking and diagnostic.
Integra JS adds a new level of maneuverability to Integra functionalities. Thanks to the Joystick tecnology, Integra
JS has an intuitive operation and guarantees a safe, precise and simple low-speed maneuverability. This makes
the mooring and the haulage operations on the trailer much easier. It includes the Trim, Boost, Heading, Anchor
and Mainstay functions.
The INTEGRA system can be used with the electro-hydraulic control unit model UIP (High Power Control Unit) or
UIPC (Compact Control Unit) depending on the desired configuration (see table).
The main PURPOSES of the INTEGRA system are the following:
-
Strengthen the steering experience with more functions, better performances and a higher level of reliability.
-
Reduce the energy consumption and noise, and better manage temperatures.
-
Simplify and make it intuitive to use it with the automatic pilot.
-
Facilitate the installation, especially in the dual station configuration.
-
Minimize the presence of hydraulic hoses.
-
Manage applications up to four engines with a single UIP power unit and up to two motors with a single UIPC
power unit.
TECHNICAL SPECIFICATIONS
Working voltage
Maximum current absorption
Circuit breaker
Operating ambient temperature
Stocking temperature
Rated voltage
Current absorption with
engine stationary
No-load
current
Current consumption
with engine at mini-
mum load
Safety valve
Certifications
UIP
9.6V-15.6V
80A
90A
-18 + 77°C
-40 + 85°C
12V
1A
7A
120 Bar (1740 Psi) 12,00 MPa
ISO 25197, ISO 10592 (ABYC P21, P24, P27)
IGNITION PROTECTED ISO 8846
User manual
UIPC
9.6V-15.6V
50A
60A
-18 +77°C
-40 + 85°C
12V
1A
4A
105 Bar (1500 Psi) 10,5 MPa
ISO 25197, ISO 10592 (ABYC P21, P24, P27)
IGNITION PROTECTED ISO 8846
page 7
INTEGRA SYSTEM
of 119
