ULTRAFLEX
2.5.1 Manual emergency manoeuvre
DANGER
This manoeuvre should only be carried out under emergency conditions in the event of a system failure.
In the case of a single engine system, proceed as follows
1. Place the engine in neutral.
2. Open the bypass valve on the electro-hydraulic power
by turning it anticlockwise until it locks
3. Turn the engine manually to the desired position.
4. Close the bypass valve by turning it clockwise until it locks.
5.
WARNING
Act on the valve manually without the use of tools .
DANGER
In this mode the boat should be operated at the lowest possible speed and only to bring the boat back to the
safety zone as you have no control over the steering system.
.
UIP POWER UNIT
UIPC POWER UNIT
UIP POWER UNIT
UIPC POWER UNIT
:
NEUTRAL
unit or the LTB6 remote bypass valve (if present)
LTB6 VALVE
LTB6 VALVE
INTEGRA SYSTEM
User manual
page 33
of 119
