Alarms and warnings
ALERT LIST
Any malfunctions, alarms or warnings are shown on the display.
To return to the main menu, press key
All possible system messages are listed below:
WARNING
Proceed with caution until the fault is resolved and the system is working properly again.
ALERT ID
REQUEST
-
-
Parameter Nr. ___ not received
0
Electric motor port stalled
1
1
Electric motor stbd stalled
Phase over current electric motor port
0
fault
2
Phase over current electric motor stbd
1
fault
0
Voltage brownout port fault
3
1
Voltage brownout stbd fault
0
Overtemp port fault
4
1
Overtemp stbd fault
0
Hall sensors port fault
5
1
Hall sensors stbd fault
0
Cylinder sensor port out of range fault
6
1
Cylinder sensor stbd out of range fault
0
Over voltage port fault
7
1
Over voltage stbd fault
page 24
of 119 -
INTEGRA SYSTEM
.
MESSAGE
ELECTRO-HYDRAULIC POWER UNIT MALFUNCTIONS
INTERVENTION
Check the CAN NMEA connections.
Contact the Technical Service.
Contact the Technical Service.
Contact the Technical Service.
Contact the Technical Service.
Check the voltage of the batteries.
Disconnect all unnecessary loads.
Contact the Technical Service.
Check the voltage of the batteries.
Disconnect all unnecessary loads.
Contact the Technical Service.
Check that the place where the electrohydraulic power
unit is installed is sufficiently cooled.
Contact the Technical Service.
Check that the place where the electrohydraulic power
unit is installed is sufficiently cooled.
Contact the Technical Service.
Contact the Technical Service.
Contact the Technical Service.
Contact the Technical Service.
Contact the Technical Service.
High supply battery voltage. Verify that the battery volt-
age value is correct. Contact the Technical Service.
High supply battery voltage. Verify that the battery volt-
age value is correct. Contact the Technical Service.
