ULTRAFLEX
ALERT ID
REQUEST
Force feedback error steering wheel 4
0
port
93
Force feedback error steering wheel 4
1
stbd
0
Missing cylinder port CAN bus message
120
1
Missing cylinder stbd CAN bus message
0
Cylinder port sensor error
121
1
Cylinder stbd sensor error
BCM EEPROM parameters missing or
150
0
corrupted
Steering wheel and cylinder port sync
0
error
151
Steering wheel and cylinder stbd sync
1
error
0
Cylinder port out of range
152
1
Cylinder stbd out of range
153
0
Cylinders port and stbd out of sync
154
0
155
0
0
Missing joystick port CAN bus message
130
1
Missing joystick stbd CAN bus message
MESSAGE
Check the good condition of the cable and CAN cable
connections (red) from the fourth station electronic
wheel to the Tee.
Check that the device is properly powered.
Check that the port and starboard power supplies are
turned on at the same time.
Contact the Technical Service.
Check the good condition of the cable and CAN cable
connections (green) from the fourth station electronic
wheel to the Tee.
Check that the device is properly powered.
Check that the port and starboard power supplies are
turned on at the same time.
Contact the Technical Service.
CYLINDER MULFUNCTION
Check the good condition of the cable and CAN cable
connections (red) from the UC120E PORT cylinder to the
Tee.
Contact the Technical Service.
Check the good condition of the cable and CAN cable
connections (green) from the UC120E STBD cylinder to
the Tee.
Contact the Technical Service.
Contact the Technical Service.
Contact the Technical Service.
BCM MALFUNCTION
Contact the Technical Service.
Contact the Technical Service.
Contact the Technical Service.
Contact the Technical Service.
Contact the Technical Service.
Check the bypass valves on the electrohydraulic con-
trol units.
Check the oil levels.
Contact the Technical Service.
Replace the electrohydraulic control unit.
Replace the electrohydraulic control unit.
JOYSTICK MALFUNCTION
Check the good condition of the cable and CAN cable
connections (red) from the first station joystick to the
Tee.
Contact the Technical Service.
Check the good condition of the cable and CAN cable
connections (green) from the first station joystick to
the Tee.
Contact the Technical Service.
INTERVENTION
page 29
INTEGRA SYSTEM
