ULTRAFLEX
2.2
Joystick
3
REF.
STATION ENABLING or DISABLING BUTTON
boat, which occurs only if the levers and joystick are in neutral (center position), the lever functions are
off (e.g., one lever) and the boat speed is lower than 3 knots (3.5mph). The display shows JOYSTICK
ON instead of AUTOCRUISE or AUTOSPORT (depending on the selected mode), and the four LEDs
light up when you take control with the joystick.
Pressing the
JOYSTICK ON mode and the system will become steerable again through levers and steering wheel.
1
CAUTION
Moving one of the control levers will bring the system out of the JOYSTICK ON mode and the system
will become steerable again through levers and steering wheel.
WARNING
For SUZUKI ENGINES, the only procedure for releasing the JOYSTICK control is to press the station
enabling button on the control levers when they are in the NEUTRAL position.
ANCHOR BUTTON: it enables/disables the ANCHOR function of the electronic anchor as described in
2
par. 2.2.2
HEADING BUTTON: it enables/disables the HEADING function of the electronic anchor as described
3
in par. 2.2.2
BOOST BUTTON: by keeping the BOOST button pressed when navigating with the joystick, engine speed
is increased in all maneuvers, this will increase the responsiveness of the boat. It can be useful, if
4
necessary, to counteract wind or swell during maneuvers.
TRIM BUTTONS: it allows adjusting the inclination of the engines to change the trim of the boat.
5
WARNING
Trim may not be supported by the engine manufacturer.
5
2
1
button when you are in control of the boat with the joystick will cause you to exit
4
FUNCTIONS
: this button
activates the joystick steering of the
INTEGRA SYSTEM
User manual
5
page 11
of 119
