3
SPECIFICATIONS
3.4
VEHICLE_________________________________________________________________
T
ires:
Front ....................... 20 x 10 - 10 Multi Rib
Rear ........................ 24 x 13 -12 Titan Ultra Trac
Tire Pressure:
Front ....................... 20 psi (1.38 BAR)
Rear ........................ 15 - 18 psi (1 - 1.2 BAR)
Battery:
Type ........................ 12 Volt Lead/Acid
Group...................... 24
Service Brake ............... 4 Wheel hydraulic drum brakes
Brake Fluid.............. DOT 3
Parking Brake ............... Integral to rear drum, hand lever
3.5
GEAR RATIOS ____________________________________________________________
84067 Gear Ratios:
5th Gear .................. 1.000:1
4th Gear ................. 1.264:1
3rd Gear ................. 1.908:1
2nd Gear ................. 3.017:1
1st Gear .................. 5.106:1
Reverse .................. 5.151:1
Hypoid Differential... 14.21:1 with 3.2:1 Reduction
84068 Gear Ratios:
3rd Gear ................. 1.000:1
2nd Gear ................. 1.536:1
1st Gear .................. 2.727:1
Reverse .................. 2.222:1
Hypoid Differential... 14.21:1 with 3.2:1 Reduction
3.6
WEIGHTS AND DIMENSIONS ________________________________________________
Dimensions:
Length............................................................ 114 (2897)
Height ...........................................................74.5 (1892)
Wheel Base .................................................. 58.2 (1478)
Turning Radius (Outside)...............................242 (6146)
en-8
All manuals and user guides at all-guides.com
Steering ........................Front wheel power steering
Hitch Capacity:
Vehicle Rated Capacity .. 2850 lb. (1293 kg)
NOTE: When calculating load weight, include 118 lb.
(53.5 kg) for the standard four post ROPS. Do not
exceed Vehicle Rated Capacity.
84069 Gear Ratios:
84063 and 84064 Gear Ratios:
Inches
(mm)
Weights:
84063 .......................................................... 1838
84064 .......................................................... 1849
84067 .......................................................... 1690
84068 .......................................................... 1503
84069 .......................................................... 1690
actuated
Max. trailer GVWR.... 1500 lb. (680 kg)
Tounge Weight.......... 200 lb. (90.7 kg)
5th Gear...................1.000:1
4th Gear ..................1.264:1
3rd Gear .................1.908:1
2nd Gear..................3.017:1
1st Gear ...................5.106:1
Reverse ...................5.151:1
Hypoid Differential ...11.16:1 with 3.2:1 Reduction
4th Gear ..................1.000:1
3rd Gear .................1.423:1
2nd Gear..................1.947:1
1st Gear ...................3.652:1
Reverse ...................3.463:1
Hypoid Differential ...11.16:1 with 3.2:1 Reduction
Lbs.
(kg)
(834)
(838)
(766)
(682)
(766)
