Item Part No.
836421
1
2 836693
3 809254
4 800695
5 800737
6 837020
7 812335
8 4184901
9 812009
10 836429
11 844956
12 894886
13 812006
14 811993
15 844951
15 844952
15 844953
16 845034
17 548952
18 836420
19 4184900
19 4211960
20 800911
21 891089
22 548201
23 894519
24 844087
25 811992
26 842360
26 836441
27 4186900
All manuals and user guides at all-guides.com
Qty. Description
1 Shaft, Input
3 Bearing, Ball
1 Ring, External Retaining
1 Ring, External Retaining
2 Ring, Internal Retaining
1 Baffle, Vent
1 Seal, Oil
1 Shaft, Main
1 Bearing, Ball
1 Collar, Engaging
1 Bearing, Bronze Thrust
1 Gear, Driven
1 • Bushing
1 Bearing, Thrust
AR Shim, .003 Thick
AR Shim, .005 Thick
AR Shim, .010 Thick
1 Collar, Thrust
1 Lockring
1 Spacer, Pinion
1 Pinion, 15 Tooth
1 Pinion, 18 Tooth
1 Nut, 9/16-18 Crown Lock
1 Jackshaft
1 Set Screw, 5/16-18 x 5/16
1 Cluster Gear
2 • Bushing
3 Shim, CLuster Gear
1 Gear, 52 Tooth
1 Gear, 49 Tooth
1 Baffle, Oil Scoop
TURF TRUCKSTER
Serial Numbers/Notes
Add or remove shims as required to
adjust gear backlash.
14.21:1 Differential (894826)
11.16:1 Differential (894825)
14.21:1 Differential (894826)
11.16:1 Differential (894825)
> Change from previous revision
