Textron Jacobsen CUSHMAN Turf Truckster Manuel De Maintenance page 193

Item Part No.
4120138
1
2 893266
3 893233
4 893234
5 844148
6 N/S
7 N/S
8 N/S
9 N/S
10 548079
11 306839
12 460030
13 471221
14 841429
15 N/S
16 800861
17 460030
18 548224
19 841167
20 450382
21 450077
22 450393
23 894573
24 894574
25 841630
26 800945
27 841738
28 841737
29 810437
All manuals and user guides at all-guides.com
Qty. Description
1 Frame, 4 Wheel Steering
2 Upper Control Arm
1 Left Side Lower Control Arm
1 Right Side Lower Control Arm
2 Upper Ball Joint
1 • Boot
1 • Boot Retainer
4 • Screw, 5/16-24 x 1 in. Hex Head
4 • Lockwasher, 5/16
4 • Nut, 5/16-24 Hex
1 • Nut, 5/8-18 Slotted Hex
1 • Cotter Pin, 1/8 x 1-1/4 in.
1 • Grease Fitting, 1/4-28 90°
2 Lower Ball Joint
1 • Boot
1 • Nut, 9/16-18 Slotted Hex
1 • Cotter Pin, 1/8 x 1-1/4 in.
1 • Grease Fitting, 1/4-28 Straight
8 Bushing, Silentbloc
8 Nut, M16-2 Locking Insert
4 Bolt, M16-2 x 90 mm Hex Head
8 Washer, M16
1 Knuckle, Left Side Steering
1 Knuckle, Right Side Steering
2 Trunnion, Control Arm
4 Bolt, M12-1.75 x 60 mm Hex Head
AR Shim, .024 in. Thick
AR Shim, .060 in. Thick
2 Clamp
TURF TRUCKSTER
Serial Numbers/Notes
Black Oxide Finish, Grade 8
Black Oxide Finish
Black Oxide Finish
Special Drive Thread
Grade 8.8
Grade 10.9
Add or remove shims as required to
adjust CASTER angle.
Add or remove shims as required to
adjust CAMBER angle.
> Change from previous revision
73
