9 PARTS CATALOG
9 PARTS CATALOG
9.1 HOW TO USE THE PARTS CATALOG _________________________________________
Abbreviations
N/S - Not serviced separately. Can only be
obtained by ordering main component or kit.
AR -Variable quantity or measurement is required
to obtain correct adjustment.
Symbols such as
indicates that a note exists which contains
additional information important in ordering that
part.
Item Part No.
1 123456
2 789012
3 345678
4 N/S
5 901234
9.2 TO ORDER PARTS_________________________________________________________
1. Write your full name and complete address on the
order.
2. Explain where and how to make shipment.
3. Give product number, name and serial number that is
stamped on the name plate or serial plate of your
product.
4. Order by the quantity desired, the part number and
description of the part as given in the parts list.
Use of other than Jacobsen authorized parts will void the warranty.
