Installation and User Manual HELO Roxx Trend
2.9

Sauna heater safety clearances

Output
kW
6,0
9,0
MIN. mm
Sensor
OLET 31
MIN. mm
Sensor
OLET 31
Figure 2 Safety distances and sensor positions.
- For wall installation, install the OLET 31 sensor 40 mm from the ceiling on the centre line of the heater.
- For ceiling installation, install it above the heater, and in line with the centre line of the heater. Do not install the
sensor anywhere else.
Sauna room
Volume Height
min. max.
m³ m³ min. mm
5 10 1900
9 13 1900
Table. 1 Safety clearance
40
A A
100 490 100
10
A A
100 490 100
10
Heater minimum clearances
From front
From side
A D
mm mm
100 300
100 350
MIN. mm
40
Sensor
OLET 31
280 D
10
MIN. mm
Sensor
OLET 31
280 D
10
Amount of stone
To ceiling
F
mm ca. kg
1070 38
1070 38
7
