Structure of the I/O Module Data
6.3

Parameter data and data formats for the process data

All parameters must always be transferred from the control to the I/O module.
6.3.1

Input module 2AI2M12E

The analog inputs are assigned to the following addresses via input parameters:
Table 16: Parameters of input module 2AI2M12E
Address
01
02
03
04
05
06
07
08
The parameters of the input modules for analog inputs are structured as follows:
Table 17: Structure of the "input channel configuration" parameter
Bit 7 Bit 6
filter,
00: Off 00: 16 bits two's complement
01: Reserved 01: 13 bits two's complement
10: Mean value 16 10: Standardized
11: Reserved
11: 16 bits direct
1)
See "6.3.2 Data formats and value ranges of input module 2AI2M12E"
The default setting for the "input channel configuration" parameter (bit 7–bit 0) is 0. If a parameter
contains the bit combination "reserved" (bit 7, bit 6, bit 2–bit 0), the default setting 0 is automatically
assigned internally for these bits.
Name
Configuration of input channel 1
Configuration of input channel 2
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Bit 5 Bit 4
1)
Data format
0: Voltage
1: Current
16 bits two's complement
Bit 3 Bit 2 Bit 1
Nominal value of the measurement
Type
range
Voltage
to
000: 0 10 V
001: ±10 V
to
010: 2 10 V
011: Reserved
100: Reserved
101: Reserved
110: Reserved
111: Reserved
Bit 0
Current
to
0 20 mA
±20 mA
to
4 20 mA
Reserved
Reserved
Reserved
Reserved
Reserved
