AVENTICS | AES I/O Modules, Analog | R412018147–BAL–001–AG
126
Appendix

12 Appendix

12.1 Accessories

Table 77: Accessories
Description
Protective cap M12x1, quantity delivered 50
Retaining bracket for intermediate mounting, quantity delivered 10
Spring clamp element, quantity delivered 10, including assembly instructions
Left end plate
Right end plate for stand-alone variant
ID label for module identification, quantity delivered 150 (5 frames of 30 labels
each); 1 label per module is required
ID label for channel identification, quantity delivered 40 (4 frames of 10 labels
each); 8 labels per module are required
Round plug connector, M12x1
Socket (female) M12x1, 4-pin, A-coded, straight 180° cable exit
Socket (female) M12x1, 4-pin, A-coded, angled 90° cable exit
Special cable for use with analog modules
Connecting cable, plug (male), M12x1, 5-pin, angled, to socket (female), M12x1,
straight, shielded, shield on pin 5 and knurl, 2 m
Mat. no.
1823312001
R412018339
R412015400
R412015398
R412015741
R412019552
R412018192
8941054324
8941054424
R412022193
