INSTRUCTIONS FOR INSTALLATION

Dismantling / Fitting glass window frame

Remove the decorative panels (fig. 8-10).
Remove the ten self-tapping screws (fig. 11) with the
spanner provided (fig. 12).
Holding the handle (fig. 13) lift the glass pane.
Now lift the pane out of the hooks by tilting the top
forwards approx 1.5 cm (fig. 13).
Twist the window frame at the bottom of the heater in
the direction (fig. 14).
Reassemble in reverse order.
For safety reasons a guard should be placed in
front of the fire at all times.
