Inhalt
1 x Technische Informationen UI-1
1 x DPM UI-1 Modul
2 x Schrauben Kombi-Torx
IN A
MIC/LINE
NRS 90xxx
Phantom Power
IN B
LINE
NRS 90xxx
IN C
DPC8000
AUDIO
CAN
+24V
CAN H
CAN L
CAN DRIVER
DPM UI-1 Block Diagram
Technical Specifications
Supply Voltage / Current
Audio Inputs
Input Level (nominal)
Input Level (max. before clip)
Input Impedance
Common Mode Rejection
Phantom Power
A/D Conversion
PCA Input
Power
CAN
Contents
1 x Engineering Data Sheet UI-1
1 x DPM UI-1 Module
2 x Screws Combination Torx
M3x10
+
+3.3 V DC, +/- 0.3 V / 6 mA
+5 V DC, +/- 0.3 V / 18 mA
+18 V DC, +/- 0.5 V / 66 mA
-18 V DC, +/- 0.5 V / 12 mA
+24 V DC / max. 1 A, depends on number of connected DPC
+48 V DC, +/- 0.5 V / 11 mA
2 x 3-pole Euro block connectors, electronically symmetric
+6 dBu / 1.55 V
Input A (MIC / LINE): +18 dBu / 6.15 V
Input B (LINE): +18 dBu / 6.15 V
Input C (PCA BUS): +12 dBu / 3.1 V
Input A (MIC / LINE): 2.5 kΩ
Input B (LINE): 20 kΩ
Input C (PCA BUS): 20 kΩ
> 80 dB (f = 1 kHz)
+48 V / 10 mA, switchable for input A
24 Bit, Sigma-Delta, 128 times oversampling
Integrated Power - CAN - Audio interface, RJ-45
+24 V DC, electronic fuse
10 to 500 kbit/s
8
Contenu
1 x Informations techniques UI-1
1 x Module DPM UI-1
2 x Vis Combination Torx
M3x10
A
D
Power Down
SELECT
Data
Select
CONTROL
GAIN
8
REGISTER
CONTROL
BOARD ID
STATUS
Reset
SPI
CAN
CONTROLLER
Electronic
Fuse 1.0A
M3x10
Slot Connector
MCLK
BCLK
WCLK
24 BIT
SERIAL
SERIAL
DATA
AUDIO
DATA
SPI
4
RES
&
CAN_INT
CAN_CS
Phantom Power
+48V
+24V
+18V
ANALOG
SUPPLY
-18V
+5V
DIGITAL
SUPPLY
+3.3V
