Inhalt
1 x Benutzerhandbuch DPC 8015
1 x DPC 8015
1 x Beschriftungsvorlage
1 x Patchkabel (3 Meter)
LINE IN
Ext. Mic
Microphone
I-Supervision
PTT
Push
Push
Button 1
Button 2
Keyboard
Display
Contrast / Brightness
DPC 8015 Block Diagram
Technical Specifications
Supply Voltage
Maximum Supply Current
(without extensions)
Maximum Supply Current
(with 5 extensions DPC 8120)
CAN Interface
Maximum Mic Input Level
Maximum Line Input Level
Maximum NF Output Level
Buttons
LEDs
LC-Display
External Connectors
Operating Temperature Range
Dimensions
Weight
Options
Emergency Button
Key Switch
Contents
1 x Owner's manual DPC 8015
1 x DPC 8015
1 x Labeling template
1 x Connecting cable (3 meter)
Mic-Amp
Limiter
Pilot Tone
Low-Pass
Pilot Tone
Line-Amp
Push
Button 3
Microcontroller
Service
Connector
Pilot
Beep
Mixer
Alert
Audio
15 to 58 V DC
< 80 mA / 24 V
< 110 mA / 18 V
< 180 mA / 24 V
< 250 mA / 18 V
10 to 500 kbit/s, 1 x RJ-45, max. length 1000 m
-21 dBu
+4 dBu
+12 dBu
5 pre-programmed, 15 programmable zone/function keys
Power (green), Fault (yellow), Alarm (red)
Green LED per pre-programmed menu button
Green and yellow LED per programmable zone/function key
Lighted LC display (122 x 32 pixel)
1 PCA BUS connector (Control data + Audio + Power supply, RJ-45)
1 Audio Source (Line level, phone jack)
1 Microphone input (phone jack)
1 EXT connector (Console Extension, RJ-12)
-5 °C to +45 °C
200 x 167 x 65 mm (without microphone)
0,6 kg
EB DPC (Part No.: F.01U.101.089)
NRS 90231 (Part No.: F.01U.101.000)
28
Contenu
1 x Mode d'emploi DPC 8015
1 x DPC 8015
1 x Gabarit d'étiquetage
1 x Câble de liaison (3 mètres)
Sym-Amp
MOS-Relay
Pilot-Detect
SPI
6MHz
Line-Amp
CAN-BUS
DC
+3.3V
-3.3V
DC
RJ-12
EXT.
RJ-45
PCA
RJ-45
BUS
