Control Port
1 x 8-pole Euro block
3 Control Inputs/Outputs
2 Reference Outputs (15 V, 100 mA / GND)
1 Ready / Fault Output
DPA GENERAL SPECIFICATIONS
Power Requirements
230 V / 115 V AC (+6% / -10%) or 24 V DC (-10% / +30%)
Protection
Audio Limiters, High Temperature, DC, Short Circuit, Mains Over/
Undervoltage Protection, DC Supply Undervoltage Protection, Inrush
Current Limiter, Ground Fault
Cooling
Front-to-Rear, temperature controlled fans
Ambient Temperature Limits
-5 °C to +45 °C
Safety Class
Class I
Dimensions (W x H x D), mm
19", 2HE, 483 x 88.1 x 374.8 mm
Weight
16 kg
Abmessungen / Dimensions
22
