Part Number
DPA 8412
Power Amplifier 4 x 125 W
Inhalt
1 x DPA 8412
1 x Netzkabel
1 x Stecker 2-pol.
Phoenix PC5/2-STF-7.62
10 x Stecker 3-pol.
Phoenix MC1.5/3-STF-3.81
4 x Stecker 6-pol.
Phoenix MC1.5/6-STF-3.81
1 x Stecker 8-pol.
Phoenix MC1.5/8-STF-3.81
DC
Mains
AC/DC
Line In 1
Diff.
AEC
Diff.
Line In 2
Diff.
Block Diagram (showing 2 channel version)
Contents
1 x DPA 8412
1 x Power cord
1 x Connector 2-pole
Phoenix PC5/2-STF-7.62
10 x Connector 3-pole
Phoenix MC1.5/3-STF-3.81
4 x Connector 6-pole
Phoenix MC1.5/6-STF-3.81
1 x Connector 8-pole
Phoenix MC1.5/8-STF-3.81
Supply
Limiter
MUX
VCA
Gain
Limiter
MUX
VCA
Gain
Pilot-Detection
Voltage, current
measurement
24
Contenu
1 x DPA 8412
1 x Câble d'alimentation
1 x Connecteur 2 pôles
Phoenix PC5/2-STF-7.62
10 x Connecteur 3 pôles
Phoenix MC1.5/3-STF-3.81
4 x Connecteur 6 pôles
Phoenix MC1.5/6-STF-3.81
1 x Connecteur 8 pôles
Phoenix MC1.5/8-STF-3.81
Protection
Power
Voltage Average
Ground fault
Protection
Power
Voltage Average
Ground fault
Spare Amp.
I/O Port
Microcontroller
D 121 844
A
Output 1
B
X
Spare
Amp.
A
Output 2
B
X
Spare
Amp.
control
CAN
