TECHNICAL INFORMATION
DCS 406R ABSCHIRMMODUL
Das Modul wird an der Rückseite des DCS 400
Rack Einschubs bestückt. Es dient zur Ab-
schirmung zwischen 100V - und NF - Modulen.
Installationshinweis
Im DCS 400 Rack Einschub sind die Slots 1-10
in aufsteigender Reihenfolge (links nach rechts)
ohne Lücken zu bestücken.
Unterschiedliche Modultypen können ansons-
ten in beliebiger Folge angeordnet werden.
Ausnahme: Der Slot 1 (Steckplatz ganz links)
muss immer mit einem DCS 401R Kontrollmo-
dul bzw. einem DCS 405R Erweiterungsmodul
bestückt sein.
Bei der Montage des Moduls und der Installati-
on der Anschlüsse ist darauf zu achten, dass
die Anforderungen der VDE 0100 und
EN 60065 eingehalten werden.
Technische Daten:
Abmessungen (B x H x T)
Gewicht
DCS 406R SHIELDING MODULE
The module is meant for insertion on the rear of
the DCS 400 rack frame providing shielding
between 100V - and LF-modules.
Always equip slots 1-10 of a DCS 400 rack
frame in ascending order (from the left to the
right) leaving no empty slots in-between.
Combining modules of different type is possi-
ble.
Exception: Slot 1 (the slot all the way on the
left) always needs to be equipped with a DCS
401R control module or a DCS 405R extension
module.
Mounting the module and establishing the con-
nections are solely admissible when performed
in accordance to VDE 0100 and EN 60065
regulations.
Specifications
:
Dimensions (W x H x D)
Weight
61
DYNACORD DCS 400 SYSTEM
Installation Notes
37.5 x 80.6 x 245 mm
71 g
