TECHNICAL INFORMATION
DCS 409R STEUER- RELAISMODUL
Das Modul wird an der Rückseite des DCS 400
Rack Einschubs bestückt. Es dient zur Umschal-
tung von Audiosignalen (Linepegel) oder für Steu-
erausgänge.
 5 NF-Relais, je 2 Umschaltkontakte.
 Vergoldete Doppelkontakte für hohe Kontakt-
sicherheit.
 Steckbare Anschlussklemmen mit Schraub-
flansch für alle Kontakte.
 5 Relais-Kontroll-LED's.
 Konfigurieren des Audioverteilers durch Tren-
nen von Drahtbrücken.
 Maximal 12 Relaismodule DCS 408R / DCS
409R / DCS 408 / DCS 409 kaskadierbar.
.
Installationshinweis
Im DCS 400 Rack Einschub sind die Slots 1-10 in
aufsteigender Reihenfolge (links nach rechts)
ohne Lücken zu bestücken.
Unterschiedliche Modultypen können ansonsten
in beliebiger Folge angeordnet werden.
Ausnahme: Der Slot 1 (Steckplatz ganz links)
muss immer mit einem DCS 401R Kontrollmodul
bzw. einem DCS 405R Erweiterungsmodul be-
stückt sein.
Bei der Montage des Moduls und der Installation
der Anschlüsse ist darauf zu achten, dass die
Anforderungen der VDE 0100 und EN 60065 ein-
gehalten werden.
Technische Daten:
Betriebsspannung
Betriebsstrom, Relais aus
Betriebsstrom, Relais aus bei 24 V
Betriebsstrom, alle Relais ein
Betriebsstrom, alle Rel. ein bei 24 V
Betriebstemperaturbereich
Abmessungen (B x H x T)
Gewicht
Relaiskontakte:
Kontaktbestückung
Kontaktwerkstoff
Kontaktbelastung
Kontaktstrom maximal
DCS 409R CONTROL RELAY MODULE
The module is meant for insertion on the rear of
the DCS 400 rack frame providing switching of
audio signals (line level) or control outputs.
 5 LF-relays, each with 2 switching contacts.
 Gold-plated double-contacts for improved con-
tact.
 Plug-in screw-flange binding posts for all con-
tacts.
 5 relay control-LED's.
 Configuring the audio signal distributor is possi-
ble through separating wire-bridges.
 Maximally 12 DCS 408R / DCS 409R / DCS 408
/ DCS 409 relay modules can be cascaded.
Always equip slots 1-10 of a DCS 400 rack frame
in ascending order (from the left to the right) leav-
ing no empty slots in-between.
Combining modules of different type is possible.
Exception: Slot 1 (the slot all the way on the left)
always needs to be equipped with a DCS 401R
control module or a DCS 405R extension module.
Mounting the module and establishing the con-
nections are solely admissible when performed in
accordance to VDE 0100 and EN 60065 regula-
tions.
Specifications
:
Operating voltage
Operating current, relays off
Operating current, relays off at 24 V 5.5 mA
Operating current, all relays on
Operating current, all rel. on at 24 V 60 mA
Operating temperature range
Dimensions (W x H x D)
Weight
Relay Contacts:
Contacts
Contact material
Contact load
Contact current max.
55
DYNACORD DCS 400 SYSTEM
Installation Notes
24V DC, -10 / +30%
5.2 mA .. 7.8 mA
55 mA .. 80 mA
+5° C .. +40° C
37.5 x 80.6 x 245 mm
185 g
2 Wechsler / 2 SPDT
AgPd + 10µ Au
1A / 24V DC
0.5A / 120V AC
2 A
