GENERAL DESCRIPTION AND FEATURES
Cooling
Operating Temperature Range
Dimensions (W x H x D)
Weight
DPM Universal Input Module
DPM Analog Output Module
CobraNet Module
Abmessungen / Dimensions
Fan, left-to-right
-5 °C to +45 °C
19", 2 HU, 483 x 88 x 376 mm
DPM 8016 (without optional modules): 7.25 kg
DPM UI-1 Universal Input Module: 100 g
DPM AO-1 Analog Output Module: 100 g
CM-1 CobraNet Module: 75 g
DPM UI-1 (Part No.: PDC-121856), 2 analog audio inputs, 1 x mic/line level, 1 x line level, electronically sym-
metric, 1 PCA input
DPM AO-1 (Part No.: PDC-121857), 2 analog audio outputs, line level, electronically symmetric
CM-1 (Part No.: D170327), 16 digital audio inputs and outputs, 2 CobraNet ports (Primary / Secondary) for net-
work redundancy
