Figure 134 : Manhattan Variable Speed Controller Alarm & Warning Codes
Description
Sensor Failure 4APT
Sensor Failure 3APT
Sensor Failure 7APT (Dryer)
Sensor Failure 2ATT
High VSD Temperature
Blower Fault
VSD Communication Failure
Check Motor Rotation
Stop Failure
Remote Stop Failure
Remote Start Failure
Incorrect VSD Type
Replace Coolant Filter (Idle Mode)
High Air Pressure
Low Sump Air Pressure
High Airend Discharge Temperature
Emergency Stop
Change Separator Element
Invalid Calibration
Check Set Points (Parameter Reset to Defaults
100 Hours To Service
Service Required
Alarm – Service Required
High Sump Pressure
Dryer High Pressure
Dryer Temperatures Warning
Change HE Filter
VSD Fault (generic)
VSD Fault 1
VSD Fault 2
VSD Fault 3
VSD Fault 4
VSD Fault 5
VSD Fault 6
VSD Fault 7
VSD Fault 8
VSD Fault 9
VSD Fault 10
VSD Fault 11
VSD Fault 12
VSD Fault 13
VSD Fault 14
VSD Fault 15
VSD Fault 16
VSD Fault 17
Unused
VSD Fault 23
VSD Fault 24
VSD Fault 25
VSD Fault 26
VSD Fault 27
Code Description
128 VSD Fault 28
129 VSD Fault 29
130 VSD Fault 30
131 VSD Fault 31
132 VSD Fault 32
133 VSD Fault 33
134 VSD Fault 34
135 Unused
136 VSD Fault 36
137 Unused
138 VSD Fault 38
139 Unused
140 VSD Fault 40
141 VSD Fault 41
142 VSD Fault 42
...
Unused
147 VSD Fault 47
148 VSD Fault 48
149 VSD Fault 49
150 AMA Not OK
...
Unused
159 VSD Fault 59
160 Unused
161 VSD Fault 61
162 VSD Fault 62
163 VSD Fault 63
164 VSD Fault 64
165 VSD Fault 65
166 VSD Fault 66
167 VSD Fault 67
168 VSD Fault 68
169 Unused
170 VSD Fault 70
171 VSD Fault 71
172 VSD Fault 72
...
Unused
180 VSD Fault 80
...
Unused
190 VSD Fault 90
191 VSD Fault 91
...
Unused
210 KTY Error (VSD Fault)
211 Fans Error (VSD Fault)
212 ECB Error (VSD Fault)
213 Broken Belt (VSD Fault)
214 Clock Failure (VSD Fault)
215 End of Curve (VSD Fault)
