Error State
F76 Door neither opens
nor closes. Invalid
sensors J4.1/2 detec-
ted
F77 Door neither opens
nor closes. Invalid
sensors J4.3/4 detec-
ted
F78 Drive blocks in end
position CLOSE
L The access to the
menu was inhibited
by the authorized
specialist dealer.
Lo Control has been in-
hibited.
U The access to the
menu was unlocked
by the authorized
specialist dealer.
If the safety circuit is
interrupted, the warn-
ing indicator is illu-
minated, see
troubleshooting.
32 - EN
Diagnosed cause
Check resistors. Check sensors.
Check resistors. Check sensors.
Check spring tension, check door
mechanics, check CLOSE end
position.
Contact specialist dealer. Menu
can only be unlocked by means
of the service tool.
Contact specialist dealer. Menu
can only be unlocked by means
of the service tool.
9 Maintenance
Tasks to be performed before starting maintenance
Hazardous voltage!
DANGER
Fatal electric shock when touching live parts. Ob-
serve the following safety rules when working on
the electrical system:
• Disconnect from the mains.
• Secure against inadvertent switch-on.
• Verify de-energised state.
• Work on the electrical system may only be
performed by skilled electricians or instruc-
ted persons working under the direction and
supervision of a skilled electrician in accord-
ance with the electrotechnical rules and dir-
ectives.
NOTICE NOTICE
For your safety, we recommend that the door
system be checked before initial use and as
needed – at least once a year – in accordance
with the check list in the Inspection chapter. The
check can be carried out by a person with the
corresponding qualification certificate or by a
specialist company.
10 Disassembly
Disassembly is carried out in reverse order of the assembly in-
structions in the Installation chapter.
11 Disposal
Dispose of packaging material in an environmentally friendly way
and in accordance with the applicable local disposal regulations.
The symbol with the crossed-out waste bin on waste elec-
trical or electronic equipment stipulates that this equipment must
not be disposed of with the household waste at the end of its life.
The separate collection of waste electrical and electronic equip-
ment aims to enable the re-use, recycling and other forms of re-
covery of waste equipment as well as to prevent negative effects
for the environment and human health caused by the disposal of
hazardous substances potentially contained in the equipment.
Dispose of the waste electrical or electronic equipment in accord-
ance with national legislation.
UK (The following applies for the United Kingdom)
According to Waste Electrical and Electronic Equipment Regula-
tions 2013 (SI 2013/3113) (as amended) devices that are no
longer usable must be collected separately and disposed of in an
environmentally friendly manner.
