17. Relay outputs
The control provides two potential-free change-over contacts
(250 V AC / 2 A, 24 V DC / 1 A).
The 24 V output at terminal X8 may be loaded with a maximum of
700 mA.
Select the desired relay function in menu items 45 and 46.
a
Fig. Connection of a red-green signaller. Select the value 0 in
menu item 45 and the value 1 in menu item 46.
b
Fig. Example: pre-warning time / acoustic signal
c
Fig. Connection for the mutual locking of 2 doors (lock circuit).
Select the value 2 or 3 in menu item 50 and the value 0 in menu
item 45.
d
Fig. Connection for the mutual locking of 3 doors (lock circuit).
Select the value 2 or 3 in menu item 50 and the value 0 in menu
items 45 and 46.
24 - EN
5 Programming
In order to program the
The programming works in a menu-controlled fashion. Carry out
all settings as specified in the Programming procedure chapter,
see also Representation of the menu structure. The Program
overview chapter shows the full scope of the menu.
Programming procedure
Proceed as follows to carry out programming settings:
1. Press the button to reach the programming of the con-
trol. The selection of the individual main menu (in the fol-
lowing referred to as "menu") appears on the LED display.
Up to 9 menus are provided.
2. Navigate with buttons
The LED display shows the current selection as value 1-9.
3. Confirm the selection with the button
in the first digit now shows the menu which you are in. The
second digit shows the current menu item in this menu.
4. Navigate with buttons
item. A total of up to 10 menu items is provided to you
(0-9). The LED display shows the current selection in the
second digit as value 0-9.
5. Confirm the selection with the button
value for the respective menu item blinks on the LED dis-
play.
6. Set the desired value using the buttons
on the menu item, values between 0 and 99 can be
entered.
7. Confirm the entry with the button
confirms the entry by 5-time blinking of the LED point and
by returning to the selection of the menu item.
8. If you want to complete the programming, press the but-
ton repeatedly until – – appears on the display.
9. Confirm the selection with the button
gramming.
T100 R
Door control, open the housing cover.
to select the desired menu.
. The LED display
to select the desired menu
. The currently set
. The LED display
to exit the pro-
. Depending
