4 Installation
Hazardous voltage
DANGER
The product works with low voltage
(230/400 V AC). Before starting with the installa-
tion,observe the following:
• Have all work on electrical connections car-
ried out by a skilled electrician.
• The power connection must be executed in
compliance with the mains voltage available.
Follow the instructions as well as the illustrations in the
"Connection diagrams" chapter.
1. Tools required
For the assembly of the control, you require the following tools:
• wooden folding rule or tape measure
• cross-tip screwdriver Phillips; size 2
• drilling machine
• drill 6 mm
• Torx screwdriver, size T20
• slotted screwdriver for electricians
• spirit level
• marking pencil
2. Opening the control cover
Open the housing cover by either loosening the two screws on
the left or right on the cover.
3. Assembly of the control
Assemble the control as specified on the drilling drawing.
Selection of the place of installation
NOTICE
When selecting the place of installation, observe
the preconditions in compliance with the tech-
nical data.
4. Terminal designation
J1 Start / pulse input (OPEN / STOP / CLOSE
J2 Photoelectric safety barrier 2- or 4-wire
J3 Safety edge OSE / 8K2 / DW / light grid
J4 Emergency stop, slack rope, locking
J5 No function
J6 Anti crash detector
J7 Key switch / pull switch
J8 Timer inputs
J9 Digital limit switch - motor cable
J10 Connection of extended controls
J11 Connection of radio receiver
J12 Antenna
J13 Membrane keypad
J14 Plug-in module (DC, RadioBand)
J15 Frequency converter (internal wiring)
J16 Service interface
X1 Power connection
X2 Power output L, N (500 W / 230 V)
X3 Protective earth contact
X4a Magnetic brake
X5 Potential-free relay contact 1, door status relay
X6 Potential-free relay contact 2, door status relay
X7 Door drive
X8a Connection light grid - sender
X8b 24 V DC, max. 700 mA
22 - EN
5. Mains connection
The control is wired in a ready-to-connect fashion using a 16 A
CEE plug and a cable with an approximate length of 1 m in com-
a
pliance with Fig. . Connect the control via an all-pole line dis-
connecter ≥ 10 A complying with the specifications of EN 12453
to the house wiring system. In doing this, ensure that the line dis-
connecter is easily accessible after the installation.
NOTICE Checking the mains connection
• Ensure that on-site fusing of 10 A is avail-
able.
• Check whether the mains connection on
site complies with the pre-wired mains con-
nection of the control.
• If the mains connection shows any devi-
ations, the control must be rewired.
• For on-site fusing, only use all-current sens-
itive residual current circuit breakers of
type B.
6. Motor connection line
a
Fig. The motor connection line is pre-assembled for the motor
and the digital limit switch DES. The connection is implemented
by fixed cable routing of the motor connection line and using cor-
responding connectors. A digital limit switch complying with PL c
as per EN 13849-1 must be used (DES3, DES4).
The magnetic brake 230 V AC is connected to connection X4.
b
Fig. Spring fracture safety device / roll-down locking mechan-
ism
If a spring fracture safety device is tripped, the control must be
protected against restart by spring fracture or roll-down safety
switches. The switches must be used as normally closed contact
subject to forced actuation complying with EN 60947-5-1, An-
nex K. With fixed cable routing, the switches are connected to the
terminal board of the DES.
7. External control devices
If you connect external control devices to terminal J1 of the con-
trol, the following variants are provided:
a
b
Fig. Connection to J1 for external control devices with
OPEN, STOP, CLOSE.
c
Fig. Connection to J1 for external control devices with a
OPEN-STOP-CLOSE switching sequence
• J1.3 - ½ door opening
• J1.4 - full door opening
Set menu item 51 to 7.
d
Fig. Connection to J1 for external control devices with a
OPEN-STOP-CLOSE switching sequence; illuminated STOP but-
ton as NO contact.
Set menu item 51 to 8.
Access by non-instructed persons only with key switch
and in dead-man mode.
Crush hazard and risk of being struck by the
CAUTION
closing door
Persons can be struck when the door is closed
or collide with the door.
• Mount external pulse transmitters always
within the range of view of the door.
• The door must be visible from the place of
operation.
