Menu 5 Various settings
Menu Entry Selection
item
50 Key switch function (J7)
0 Pulse input OPEN/CLOSE (default setting)
1 Inhibit control panel
2 Inhibit external control elements
3 Inhibit control panel and external control
elements
4 Activate control elements for 10 seconds
5 Switch-over to dead man mode for closing
6 Switch-over to 1/2 opening (winter mode)
7 Pulse input OPEN-STOP-CLOSE
8 Pulse input 1/2 OPEN-STOP-CLOSE
9 Automatic closing AR
10 Pulse input for smoke and heat extraction sys-
tem (setting in menu item 55)
11 Pulse input for smoke and heat extraction sys-
tem, inverted (setting in menu item 55)
12 Mutual locking of door
51 Function of external control devices
0 off (default setting)
1 Dead man open / dead man close
2 Pulse open / dead man close
3 Pulse open / pulse close
4 Pulse 1/2 door opening / pulse close
5 AR operation, automatic closing
6 AR operation, 1/2 door opening
7 Open-close operation
8 Open / close pulse as NO contact
52 001-256 Entry of control address
53 Plug-in module
0 off (default setting)
1, 2, 3, 4 DC module
5 RSE system with OSE
6 RSE system with 8k2
55 Door setting for smoke and heat extraction
system position
58 RSE selection of wicket door contact
Press for 5 s: delete pairing of RSE-system
0 ENS-8200
1 ENS-S 68xx (default setting)
2 NC contact
- - Exit menu
28 - EN
Menu 6 Radio
Menu Entry Selection
item
60 Programming the start button on the hand-held
transmitter
61 Programming the 1/2 opening button on the hand-
held transmitter
62 Programming the light button on the hand-held
transmitter
63 Deleting radio codes
Press for 5 s
64 Hand-held transmitter operating mode
0 off (default setting)
1 Pulsed operation open/stop/close
2 Automatic closing AR
3 Open/close operation
- - Exit menu
Menu 7 drive settings
Menu Entry Selection
item
70 Soft start with reduced torque
0 Off
1 - 13 Time 60 ms - 300 ms (in steps of 20 ms)
71 0 - 40 Deceleration path before reaching upper end
position in cm (10 cm = default setting)
72 0 - 20 Reduced torque (16 = default setting)
73 Selection of drive
0* High-speed doors and sectional doors
(> 15 revolutions/min)
1 Roller doors (< 15 revolutions/min)
- - Exit menu
Menu 9 Service menu
menu Entry Selection
item
90 Selection of the door maintenance cycle
0 No service interval (default setting)
1 10000 cycles
2 20000 cycles
3 30000 cycles
4 40000 cycles
5 50000 cycles
6 60000 cycles
7 80000 cycles
8 100000 cycles
9 120000 cycles
10 150000 cycles
11 200000 cycles
12 250000 cycles
91 Cycle counter output door cycles
T100 R
