8. Timer inputs
If you want to connect control devices in AR operation to ter-
minal J8 of the control, the following options for connection are
provided:
a
Fig. Connection for pull switch and pressure switch
b
Fig. Connection for an induction loop detector (230 V)
c
Fig. Connection for a motion detector.
When the open time set in menu item 44 has elapsed, the door
closes automatically. You can select a reduced open time by
means of the photoelectric sensor in menu item 38. In order to re-
duce the open time, a photoelectric sensor or a light grid is re-
quired at terminal J2.
9. Approach area monitoring
Crush hazard and risk of being struck by the
WARNING
closing door
If the closing speed exceeds 50 cm/s, the move-
ment area on both sides of the door needs be
monitored over the entire door width and to a
depth of 90 cm.
The connection diagram depicts the approach area monitoring by
means of a motion and presence sensor by Condor.
10. Door connection box
a
Fig. The door connection box allows for the connection of a
safety edge, a wicket door contact and slack rope switches. The
wicket door contact and the slack rope switches are electrically
connected in series and are monitored by the control. If a wicket
door is available, the wicket door contact (Entrysense 6k8 model)
is connected to the door connection box. For this purpose, re-
move the 2 kOhm resistor from the door connection box, to which
the Entrysense is clamped, and connect it there. The Entrysense
is tested in compliance with PL c as per EN 13849-1 and is mon-
itored by the door control.
As slack rope switches, switches with forced actuation complying
with the specifications of EN 60947-5-1, Annex K are to be used.
The supply line of the door connection box is to be laid at the
door leaf, well protected against damage. With pulsed operation,
connect a closing edge safety device and select the correspond-
ing setting in menu item 35. Pressing the Prog button
menu item 35 for a longer time displays the measured resistance
value of the 8k2 closing edge. Example: Value 82 means 8k2.
Pressing the Prog button
Crush hazard and risk of being struck by the
CAUTION
closing door
The pressure wave switches may only be actu-
ated after having been tested.
• For this purpose, select the value 2 in menu
item 35.
b
Fig. Connect a door connection box with a break-away sensor
and an OSE (optical closing edge safety device).
c
Fig. Connect a door connection box with a break-away sensor
and an 8k2 closing edge safety device).
When using a RSE module, a light grid or another safety
solution, connect the 8k2 resistor directly to terminal J3. Value 1
has to be selected in menu item 35.
briefly will interrupt the display.
11. Light grid
Danger due to missing monitoring of the
CAUTION
movement area in AR operation
When using a light grid with "blanking function" in
AR operation, additional monitoring of the move-
ment area must be provided.
Instead of the closing edge safety device, the following light grids
can be connected:
a
Fig. A light grid by Telco with "SG14" testing. Set the value
to 1 in menu item 36.
b
Fig. A light grid by Telco with "SG15" OSE interface. Set the
value to 0 in menu item 35.
c
Fig. A light grid by CEDES with "GridScan/Mini-SB-2" OSE in-
terface. Set the value to 0 in menu item 35.
d
Fig. A light grid by WITT with "LIGI" OSE interface. Set the
value to 0 in menu item 35.
12. Photoelectric sensor
Connect the photoelectric sensor as specified for the following
variants:
a
Fig. 2-wire photoelectric sensor LS2
b
Fig. 4-wire photoelectric sensor LS5 with testing
c
Fig. Reflection light barrier
Then select the corresponding photoelectric sensor under menu
item 36.
If you have selected "Photoelectric sensor mounted in the frame",
the next CLOSE run executed by the control is a "learning cycle"
for detecting the position.
NOTICE Do not interrupt the learning cycle for
detecting the position of the photoelectric
sensors
The automatic position detection of the installed
photoelectric sensor must not be interrupted.
13. Anti crash sensor
Via a connected anti-crash sensor, input J6 detects when the cur-
in
tain is off guide and starts automatic threading up.
a
Fig. One-way light barrier with relay output (SMR32xx /
SMT30xxC)
b
Fig. One-way light barrier with transistor output (ELS-300 NO)
14. STOP circuit
a
Fig. Emergency stop connection
Connect the emergency stop button to terminal J4.3/4.
b
Fig. Connection of the roll-up protection mechanism
To provide for protection from being drawn in, with fixed cable
routing a roll-up protection mechanism with an evaluation unit can
be connected to the safety circuit J4.3/4. The evaluation unit must
comply with PL c Cat3 as per EN 13849-1.
Also use this input to connect a spring break switch.
15. Key switch
When connecting a key switch to the connection terminal J7 (see
illustration), the control has to be programmed accordingly. Select
the desired function in menu item 50 "Key switch function".
16. Radio receiver
For the use of a hand-held transmitter, attach the receiver module
(option) to J11 as shown in the illustration and connect the an-
tenna to J12. In order to program the hand-held transmitters, fol-
low the instructions provided in Programming a radio hand-held
transmitter in the Programming chapter.
