panicLock AP4
Emergency unlocking in direction of escape
• The door can be opened from inside at all
hours as an emergency exit.
• The door can be opened from the inside with
a single action.
• Very easy to operate in an emergency with
DIN-compliant handle position.
Notice:
Two panic opening variants:
• GFS-entryguard, EN 179 one-
handed
• entryguard DENI Exit 2.3100100
Handle height for adults at 1550 mm
(continuous access possible).
Opening
Application 1:
• mechanical opening (function B) with inside
and outside handle in upper handle position
• temporary manual activation of the outside
handle possible during pick-up and delivery
times (function B)
Application 2 (optional):
• mechanical opening with inside handle in
upper handle position (use of same locking
device, omission of outside handle)
• for single sash doors with locking function B
or E (omission of upper outside handle) and
double sash doors with fixed inactive sash
without panic function
