Installation, Operating and
Maintenance Instructions
EN
Function III:
5
Function IV:
Drk:
Kmb:
Aug. Winkhaus GmbH & Co. KG ∙ Berkeser Straße 6 ∙ 98617 Meiningen
T +49 369 3950 - 0 ∙ www.winkhaus.de ∙ Subject to technical changes
panicLock AP4
Split follower, continuously operative emer-
gency door function from inside. Opening from
inside is always possible with the inside fitting.
The outside fitting is always coupled or always
uncoupled by means of the key. The dead bolt
is only actuated from outside with the key. After
actuation of the fitting / emergency door func-
tion from inside, the door must also open from
outside until it is locked again manually, reverse
escape is possible.
Transit function D
Split follower, continuously operative emer-
gency door function from inside. Opening from
inside is always possible with the inside fitting.
The outside fitting is always coupled or always
uncoupled by means of the key. The dead bolt
is only actuated from outside with the key. After
actuation of the fitting / emergency door func-
tion from inside, the door must not also open
from outside by means of the fitting.
Change-over function B.
Indicates the hardware in accordance with the
table "Handles" that may be used with the lock.
Indicates the hardware in accordance with the
table "Panic push bars" that may be used with
the lock.
