Depth-Gauge Clearance
1. The depth gauge should be
maintained at a clearance of 0.025 in.
(0.64 mm), as shown in Fig. 33. Use a
depth gauge tool (available separately)
to check the depth gauge clearances.
2. Check the depth-gauge clearance
every time the chain is filed. Use a
flat file and a depth-gauge jointer
(both available separately) to lower
all gauges uniformly (Fig. 34). Use
a 0.025 in. (0.52 mm) depth-gauge
jointer.
3. Depth-gauges must be adjusted
with the flat file in the same
direction the adjoining cutter was
filed with the round file. Use care
not to contact the cutter face with
the flat file when adjusting depth
gauges.
40
CORDLESS 12" COMPACT CHAIN SAW — CS1200/CS1200-FC
33
Depth Gauge Clearance
34
Depth Gauge
Jointer
0.025" (0.64 mm)
Flat File
