1. Guide Bar
2. Saw Chain
3. Chain-kickback Brake Paddle
4. Rear Handle
5. Front Handle
6. Oil-inspection Window
7. Oil Tank Cap
8. Locking Tongue
WARNING :
information on the product and in this instruction manual, as well as knowledge of
the project you are attempting. Before use of this product, familiarize yourself with all
operating features and safety rules.
Chain-kickback Brake Paddle
Serves as the lever for chain brake activation. It also provides protection against
projecting branches and helps prevent the left hand from touching the saw chain if it
slips off the front handle.
Trigger Switch
Turns the chain saw On and Off and adjusts the chain speed.
Locking Tongue
Helps to prevent accidental or unauthorized activating of the trigger switch. It must be
depressed before the trigger switch can be activated.
Oil-tank Cap
Seals the oil tank.
Oil-inspection Window
Provides a view of the oil level in the oil tank.
20
CORDLESS 12" COMPACT CHAIN SAW — CS1200/CS1200-FC
The safe use of this product requires an understanding of the
9. Trigger Switch
10. Battery-release Button
11. Side Cover
12. Chain-tensioning Knob
13. Side-cover Knob
14. Lubricating Hole
15. Chain Sheath
16. Lanyard Eyelet
