6.6 Sensors
Combi sensor humidity adjustment
Combi sensor temperature adjustment
Combi sensor operation
Rel. humidity min value limit
Rel. humidity max value limit
Sensor 1 configuration:
Sensor 1 type
Name of sensor 1
Sensor 2 configuration:
Sensor 2 type
Name of sensor 2
Sensor 3 and 4 configuration selection active
if simple control unit parameter switched to
inactive
CO
value limit min.
2
CO
value limit max.
2
VOC value limit min.
VOC value limit max.
CO
value control voltage 0 V
2
CO
value control voltage 10 V
2
VOC value control voltage 0 V
VOC value control voltage 10 V
Rel. humidity control voltage 0 V
Rel. humidity control voltage 10 V
Combi sensor humidity adjustment
Combi sensor temperature adjustment
Parameter
Combi sensor humidi-
ty adjustment
Combi sensor temper-
ature adjustment
Corrects any deviations which may arise in
the combi sensor humidity/temperature value.
Setting
-15 ... 0 ... 15 %
-3 ... 0 ... 3 °C
6 Settings main menu | UK
Combi sensor operation
Rel. humidity value limit
Parameter
Combi sensor
operation
Rel. humidity
min. value limit
Rel. humidity max
value limit
stepped: Rel. humidity value limit max for
intensive ventilation. The maximum value
always serves, independently from the set
operating mode, as a switching point for
dehumidification. The minimum value is not
taken into account.
linear: Rel. humidity value limit min/max
for intensive ventilation with linear humidity
control in Auto Sensor operating mode. The
maximum value always serves, independently
from the set operating mode, as a switching
point for dehumidification. The minimum
value applies to reduced ventilation. Between
RV and IV, regulation is linear, stepless and
demand-based.
Setting also applies to nominal ventila-
i
tion for simple control unit in solo mode
and linear setting.
The value limit settings apply to the
i
internal combi sensor and any external
humidity sensors which may be con-
nected.
Configuration of sensor 1 / sensor 2
Parameter
Sensor 1 / sensor 2
configuration
Sensor 1 / sensor 2
type
Name
sensor 1 / sensor 2
Setting
stepped / linear
30 ... 35 ... 45 % rel.
hum.
50 ... 60 ... 70 % rel.
hum.
Setting
no / yes
CO
, VOC, rel. hum.,
2
digital
Sensor 1, sensor 2,
sensor 3, sensor 4,
bathroom, WC,
kitchen, bedroom,
children's room, living
room, zone 1, zone 2
73
