Introduction - Simco ION Performax Easy Ex Mode D'emploi

1 Introduction

The Performax Easy Ex and Performax Easy Ex Speed static bars are designed to neutralize
electrostatically charged surfaces and may be used in certain hazardous areas (see also
Section 3, Safety).
The main difference between these two static bars is their recommended use;
the Performax Easy Ex is suitable for general applications, the Performax Easy Ex Speed is
suited for high web speeds, close to the material to be discharged.
Both static bars are equipped with an integrated high voltage power supply, emitters and a
status LED.
The Performax Easy Ex Speed is supplied with a 24 V DC supply voltage via a cable with 5
conductors.
The Performax Easy Ex is optimally deployed between 100 and 300 mm away from the material
at material speeds below 500 meters per minute and is available in effective lengths of 270
through 2790 mm in increments of 180 mm.
For material speeds exceeding 500 meters per minute and / or material distances between 50
and 300 mm the Performax Easy Ex Speed is recommended. This is available in effective
lengths from 90 through 2790 mm, in increments of 60 mm.
Fixed connecting cable,
with protective hose
(standard) or without
protective hose
(optional).
Image 1.1: Connection side Performax Easy Ex (Speed)
PerformaxEasyExPerformaxEasyExSpeed_UM_9752153010_NL_D_ GB_F_V2_3
Emitters
Status LED
Mounting bracket
52
