Packet- For each available interface, the Status/WAN-statistics/Packet-transport-
transport-
statistics menu option provides statistics on the data packets transferred via this
statistics
interface. The table maintained here has the following layout:
Ifc
Ch01
Ch02
Below is a detailed description of the meaning of each field:
Ifc
Rx
Tx-total
Tx-normal
Tx-reliable
Tx-urgent
Error-statistics For each available interface, the Status/WAN-statistics/Error-statistics menu option
provides statistics on the transmission errors that have occurred on this interface. The
table maintained here has the following layout:
Ifc
Ch01
Ch02
Below is a detailed description of the meaning of each field:
Ifc
Rx-l1-error
Rx-l2-error
Rx-l3-error
Stack-error
Tx-error
Rx Tx-total
0 0
0 0
Designates the associated channel.
Number of packets received
Number of packets sent (data and protocol packets)
Number of normal data packets sent
Number of data packets transferred with secured handling
Number of data packets transferred with priority handling (urgent queue)
Rx-l1-error Rx-l2-error
0 0
0 0
Designates the associated channel.
Number of layer-3 errors in data received (i.e., the protocol header of layer-3 is
incorrect)
Number of layer-2 errors in data received (i.e., similar to the layer-3 errors, e.g.
defective PPP header)
Number of layer-1 errors in data received (similar to layer-3 errors)
Number of transmission errors that occurred while sending
Number of stack errors for data received. Stack errors are caused when frames
are received that cannot be assigned to an internal processing procedure (e.g. IP
router).
Description of the menu options
Tx-normal Tx-reliable
0 0
0 0
Rx-l3-error Stack-error
0 0
0 0
