Turning the machine off
- Before putting the robotized units in the idle
status and turning the aligner off, make sure
that in the working area there are no obstacles
that can hinder movement of the robotized
units or lift.
- Lower the lift to the floor.
- Carry out the correct sequence of controls to
turn the aligner programme off (see the "Exam-
ple of a wheel aligner check" paragraph).
GENERAL
CHARACTERISTICS
- Display of angle data with 0.01° resolution.
- Databank on Hard disk or USB PEN DRIVE.
- User databank and jobs archive.
- Guide to vehicle adjustment with stationary
or animated images.
- 27" SVGA LCD colour monitor (minimum resolution
800x600 pixels, 256 colours).
- Professional alphanumeric keypad.
- Great operating freedom, possibility of going from
one adjustment to another as desired.
- Data displayed in degrees, grades, millimetres
and inches.
- Graphic comparison between the data read
and the databank values.
- Vehicle chassis diagnostics.

TECHNICAL DATA

- Measuring ranges:
toe...............................................................± 24°
camber .......................................................± 10°
caster ..........................................................± 30°
king pin ......................................................± 30°
setback .......................................................± 22°
thrust angle................................................± 22°
steering angle............................................± 24°
60
- Power supply:
230 Vac central unit: (50-60 Hz) single phase
single robotized unit:
central unit consumption ....................... 280W
- Dimensions (LxWxH):
central unit (without target and 17" monitor):
central unit (without monitor):
robotized unit:
- Weight:
central unit ............................................ 200 kg
target ...................................................... 100 kg
electrical/electronic components ....... 100 kg
- Ambient conditions for machine storage:
relative humidity ............................ 20% - 80%
temperature range ..................-10°C ÷ +60°C.
- Ambient conditions in the place of opera-
tion:
110
relative humidity ............................ 20% - 80%
temperature range ..........................5°C - 40°C
- Necessary light level in working condi-
tions: ............................................... 300 lux
- Noise level when operating: ........≤70 db(A)
- Artificial light source classification:
Measuring light (single) ..................... class 3B
Field light (single) .............................. class 3B
Laser diodes (pair) ............................. class 3B
Stadimeter ..............................................class 2

WHAT A WHEEL ALIGNER IS

An aligner or wheel aligner is defined as an
instrument for measuring characteristic align-
ment angles of a vehicle (see the "Characteristic
angles" section).
Characteristic values
1) ROC (Run Out Compensation). Off-centre
and plane error compensation.
ROC renders the angle measurements inde-
pendent of geometrical errors in the rim and/or
wheel mounting.
This procedure should be performed on all
wheels.
2) Toe.
Angle formed by the equatorial plane of the
wheel and the axis of symmetry or thrust axis of
the vehicle (Figs.10 and 11).
The axis of symmetry of the vehicle is the im-
aginary line which divides the vehicle in half
Operator's manual R.E.M.O. COMPACT
230 Vac (50-60 Hz) single phase
3605 x 580 x 2810 mm
860x 320 x 1740 mm
980 x 440 x 2500 mm
