Installation space

WARNING
Choose the place of installation in strict obser-
vance of local regulations regarding safety in
the workplace.
The floor must be able to withstand a load
equal to the sum of the weight of the equipment
itself and the maximum payload, bearing in
mind the lift support surface area and anchor
fixtures used.
Figure 102 illustrates the layout and relative
nominal installation area of a complete system
in which the robotised units are equipped with
"5-5-6" type heads. Therefore, the working space
necessary to installation of a complete clampless
wheel alignment measurement system is: L x W
x H = 9.20 x 5.20 x 2.50 m3
Operator's manual R.E.M.O. COMPACT
WARNING
Always keep a safe distance when the robotized
units are moving. Also avoid looking directly at
the artificial light sources (laser and lights).
IMPORTANT: for correct, safe use of the equip-
ment, users must ensure a lighting level of at
least 300 lux in the place of use.
