Maintenance

To enter programming mode, press buttons 'On/Off' and 'Mode-switch' for two seconds. Four
zeros will appear, with the first zero blinking.
Enter the appropriate code by pressing button '+' for a higher value, '-' for a lower value. Press
button 'On/Off' to select a value and move to the next digit. After entering the correct value for the
fourth digit, press button 'On/Off' to move into the chosen menu. In the programming menu,
buttons '+' and '-' will move to a higher or lower value. Pressing button 'On/Off' will save the entry
and move you to the next step, or back to the regular display.
Codes
2001
allows you to switch between miles and kilometers.
2004
allows you to set the time.
2009
allows you to swap the function of the buttons from left to right and vice versa.
3771
allows you to set the correct wheel diameter.
2011
allows you to change the display language. Use button to scroll through the languages.
5. Maintenance
After the first two to three weeks of use, or 300km, have your dealer check the spokes in the rear wheel.
Check the connections of the system every two to three months. Make sure that no dirt or moisture
can get into the 'docking station' (connector) when the battery-pack is not on the bike. If you notice
anything like this, clean with a smooth, dry brush.
The motor is of the 'brushless' type and requires no maintenance.

5.1 Cleaning

When cleaning the bike, use a sponge and/or a soft brush. For the battery-case, a damp cloth
suffices. Use little water. Keep water away from the electrical connections.
Notice: Do not use a jet-wash. The powerful water-jet may damage the electronics.
5.2 R emoval and refitting of wheels for bikes with a rear wheel motor
Removal and refitting of the rear wheel is best left to your dealer. If you are forced to do it yourself,
follow the instructions.
• Removal of the rear wheel
1. Make sure that the system is switched 'Off'.
2. Change to the highest gear.
3. Remove the battery from its docking station.
4. Unplug the connectors of the motor at the left hand
side of the hub. Make sure that both cables are
unplugged. (see photo)
5. Disconnect the rear brake:
-V-brakes, Magura brakes: release the rear brake
- Rollerbrakes: unhook the cable and housing stop from
the brake. Undo the reaction arm bolt
6. Loosen and remove the axle nuts.
