Instructions for Use
4.3 R IDE+ EASY Controller
1• Battery level 2• Light indicator, On or Off 3• Side button (On/Off, Light On/Off) 4• Front + (right
hand) button 5• Front - (left hand) button 6• Level indicator
• Switching system On / Off
To switch the system on, push the Side button once. The battery- pack will
emit four short 'beeps' and the system will do a self-check. This is shown
on the display as a building up of the display: the bicycle outline shows
first, then the state of charge of the battery is shown. To switch the system
off, press the Side button again. The battery-pack will emit five short
'beeps'. There is no difference between riding with the system 'on' in level
'0' or 'off'. If the bike is left with the system on, it will automatically switch off after about 10 minutes.
• Assistance/(Regeneration) Level
There are four levels of assistance. The bars behind the bicycle wheel in
the display show in which assist-level the system is. For pedaling
assistance, press the '+ (right hand)' button. For assistance level 1,
press once. Press again for more assistance. Push the '-(left hand)'
button to go to a lower level. When bars behind the bicycle wheel in the
display are all outlined only, you are pedaling a normal bicycle. When
the rear brake is pulled, the system switches to generating. The two
upper bars in the display will blink.
Regeneration levels are not installed as standard on the controller. This means that the motor will only
generate energy when the rear brake is pulled. However, if you want to, your dealer can activate the
regeneration levels. Regeneration levels can be controlled in a similar way if no level is activated on
the controller. Push '-' button once for regeneration level 1, again for higher levels. Push '+' button to
go to a lower level.
Notice: It is strongly advised to ride away in a straight line when an assistance level is selected.
Never select assistance level 3 or 4 during maneuvering or riding away in a tight corner. The powerful
reaction of motor might take you unawares.
• Switching lights On / Off
For bikes equipped with lights: keep the 'Side' button pressed for five
seconds to switch lights on or off. This switches on the front light, the
rear light and the backlight in controller screen. In the display, the
light symbol will appear. The lights will stay on even when you stop.
