4.2 R IDE+ Pro controller
1• Speed indication 2• Battery level 3• '+' button 4• '-' button 5• Distance, Odometer, Chronometer,
Average speed, Clock 6• Current assistance level 7• Current generation level 8• Mode-switch
button 9• On/Off button 10• Light indicator, On or Off
• Switching system On / Off
Press any of the two top buttons to switch the system on.
The battery will beep four times, the system will perform a
short self-check (shown on the display as a countdown in the
'speed'-field), and the system will activate (switch to 'on').
As soon as the system is 'on', the screen will display and each
function will be shown next to its corresponding button.
To switch the system off, press the
will beep five times. Riding with the system 'on' in level 0 is the
same as riding with the system 'Off'. If the bike is left with the
system on, it will automatically switch off after about 10 minutes.
• Changing the position of the buttons
Normally, the On/Off button
are on the right, and the '+' and '-' buttons on the left. The
functionality of the buttons can be swapped right-to-left. The code
to access this is 2009. More information about programming via
the controller can be found later in this manual.
• Assistance
When the motor provides power, the bicycle is in assistance mode. There are four levels of
assistance. The level of assistance is shown by the arrows at the bottom of the display.
Notice: It is strongly advised to ride away in a straight line when an assistance level is selected.
Never select assistance level 3 or 4 during maneuvering or riding away in a tight corner. The powerful
reaction of motor might take you unawares.
To increase assistance, press button '+'. For assistance level 1,
press once. Press again for more assistance. For less assistance
press button '-'. When there is no assistance level shown, there is
no assistance so riding is the same as pedaling a normal bicycle.
4 1
7
button . The battery-pack
and the mode-switch
Instructions for Use
2
3
5
4
6
button
