Instructions for Use
4.4 RIDE+ EASY II Controller
1• Level indicator 2• Side button (On/Off, Light On/Off) 3• Light indicator, On or Off 4• Battery
level 5• Front +(right hand) button, Miles/Kilometer switch button 6• Front -(left hand) button,
Mode switch button 7• Distance, Odometer 8• Speed indication
• Switching system On / Off
To switch the system on, push the 'Side' button once. The battery- pack
will emit four short 'beeps' and the system will do a self-check. To
switch the system off, press the 'Side' button again. The battery-pack
will emit five short 'beeps'. There is no difference between riding with
the system 'on' in level '0' or 'off'. If the bike is left with the system on,
it will automatically switch off after about 10 minutes.
• Assistance/(Regeneration) Level
There are four levels of assistance. The arrows in the right top corner of
the display show in which assist-level the system is. For pedaling-
assistance, press the '+ (right hand)' button. For assistance level 1, press
once. Press again for more assistance. Push the '- (left hand)' button to
go to a lower level. When arrows in the right top corner are all outlined
only, you are pedaling a normal bicycle. When the rear brake is pulled,
the system switches to generating and two arrows on the display will
start blinking.
Regeneration levels are not installed as standard on the controller. This means that the motor will
only generate energy when the rear brake is pulled. However, if you want to, your dealer can
activate the regeneration levels. Regeneration levels can be controlled in a similar way if no level
is activated on the controller. Push '-' button once for regeneration level 1, again for higher levels.
Push '+' button to go to a lower level.
Notice: It is strongly advised to ride away in a straight line when an assistance level is selected.
Never select assistance level 3 or 4 during maneuvering or riding away in a tight corner. The powerful
reaction of motor might take you unawares.
• Switching lights On / Off
Press the 'Side' button for 2 seconds to switch On / Off the Controller
display light, and if present, the front and rear lights. Once activated,
the light symbol
even when you stop. Even when the battery-gauge shows 'empty', there
26
8
7
6
will appear on the screen. The lights will stay on
1
2
3
4
5
