2. Description

2.1. Specific parts for the electric bicycle
1
There are several models of electric bicycles, with different equipment options. Find the options
that are on your electric bicycle. In the pictures of the bikes you will see the battery-pack (1), the
motor 'front or rear' (2), the controller (3), the brake switch (4), and the wiring harness (5).
• Battery-packs
There are four types of batteries for RIDE+ bicycles:
1 'RIDE+ R250 Battery-pack', containing 30 Li-Mn (Lithium-Ion) cells, 4.8 Ah, 250 Wh.
2 'RIDE+ R320 Battery-pack' (2 editions), containing 39 Li-Mn (Lithium-Ion) cells, 6.6 Ah, 320 Wh.
3 'RIDE+ C320 Battery-pack', containing 39 Li-Mn (Lithium-Ion) cells, 6.6 Ah, 320 Wh
4 'RIDE+ C420 Battery-pack', containing 52 Li-Mn (Lithium-Ion) cells, 8.8 Ah, 420 Wh
1
• Motor configurations
1 250W RIDE+ rear motor, derailleur and roller brakes
2 250W RIDE+ rear motor, derailleur and disc brakes or rim brakes (Magura or V-brake)
3 250W RIDE+ rear SL motor (lightweight), derailleur and roller brakes
4 250W RIDE+ rear SL motor (lightweight), derailleur and disc brakes or rim brakes (Magura or V-brake)
5 250W RIDE+ Front motor, Internal gear hub and roller brakes
6 250W RIDE+ Front motor, Internal gear hub and rim brakes (Magura or V-brake)
1 2
3
4
5
2
2
3 4
2
2
5
Description
3
4
5
1
3 4
6
13
