Instructions for Use

4. Instructions for Use
There are four types of controller: BionX G2, RIDE+ Pro, RIDE+ EASY and RIDE+ EASY II.
4.1 B ionX G2 controller
1• Speed indication 2• Distance, Odometer, Chronometer, Average speed 3• Current assistance
level 4• Current generation level 5• On/Off
'-' button 9• Battery level
• Switching system On / Off
Press any of the two top buttons to switch the system on.
The battery will beep four times, the system will perform a
short self-check (shown on the display as a countdown in the
'speed'-field), and the system will activate (switch to 'on').
As soon as the system is 'on', the screen will display and each
function will be shown next to its corresponding button.
• Same as in the Quick Start
To switch the system off, press the
pack will beep five times. Riding with the system 'On' in level 0
is the same as riding with the system 'Off'. If the bike is left with
the system on, it will automatically switch off after about 10
minutes. Same as in the Quick Start
• Changing the position of the buttons
Normally, the On/Off button
button are on the right, and the '+' and '-' buttons on the left.
The functionality of the buttons can be swapped right-to-left.
The code to access this is 2009. More information about
programming via the controller can be found later in this
manual.
• Assistance
When the motor provides power, the bicycle is in assistance
mode. There are four levels of assistance. The level of
assistance is shown by the bar graph on the right, below the
digits for speed. The narrow graph on the display shows the
amount of energy delivered to the motor.
18
4
5
6
button . The battery-
and the mode-switch
3
1
9 2
button 6• Mode-switch
7
8
button 7• '+' button 8•
