21. Technical specifications
Summary of important technical specifications
Vacuum performance:
-75 mmHg to -300 mmHg
45 to 70 cpm
Transmission standard: Bluetooth® Low Energy 4.2
Bluetooth range: up to 10 m
Bluetooth encryption: 128-bit AES-CCM for secure connections
Frequency range: 2400-2483.5 MHz
Max. power output: +4 dBm
Battery capacity
and type
Battery runtime
Size
Weight
Ingress protection level
3.7V, 970 mAh (rated) Li-ion
Approximately 2.5 hours
126 x 112 x 71 mm
200 g ±10 g
IP22
Operating temperature range
5°C to 35°C
Operating humidity range
(15% to 90% relative humidity)
Operating ambient pressure range
(70 kPa to 106 kPa)
Transport/storage temperature range
-20°C to 50°C
Transport/storage humidity range
(20% to 93% relative humidity)
