Cameo AZOR SP2 IP Manuel D'utilisation page 184

13 14
15
14 16
15 17
18
19
20
16 21
17 22
18 23
19 24
184
000 - 128 Gobo Position 0° ... 540°
Gobo Wheel
129 - 191 Gobo Rotation fast to slow
18 1 Gobo
192 - 192 Gobo Rotation Stop
Position
193 - 255 Gobo Rotation slow to fast (backwards)
Gobo Wheel
1 Gobo
19 000 - 255 Gobo Position fine
Position
fine
20 Zoom 000 - 255
21 Zoom fine 000 - 255
22 Focus 000 - 255
23 Focus fine 000 - 255
000 - 005 No function
006 - 036 3m
037 - 067 5m
068 - 098 10m
24 Auto Focus 099 - 129 15m
130 - 160 20m
161 - 191 30m
192 - 222 50m
223 - 255 100m
Auto Focus
25 000 - 255 Auto Focus Adjustment
Adjust
000 - 191 Open to Close
192 - 200 Pulse slow to fast (with Dim)
201 - 209 Pulse slow to fast (without Dim)
210 - 218
26 Iris
219 - 227 Ramp up slow to fast (with Dim)
228 - 236 Ramp up slow to fast (without Dim)
237 - 245 Ramp down slow to fast (with Dim)
246 - 255 Ramp down slow to fast (without Dim)
000 - 005 Prism Off
006 - 091 Prism 1
Prism
27
Selection
092 - 175 Prism 2
176 - 255 Prism 1 & 2
000 - 128 Prism Position 0° to 540°
129 - 191 Prism Rotation fast to slow
28 Prism 1
192 - 192 Prism Rotation Stop
193 - 255 Prism Rotation slow to fast (backwards)
000 - 128 Prism Position 0° to 540°
129 - 191 Prism Rotation fast to slow
29 Prism 2
192 - 192 Prism Rotation Stop
193 - 255 Prism Rotation slow to fast (backwards)
Narrow to Wide
0% to 100%
Pulse Random slow to fast (without
Dim)
