WIRELESS DMX
To pair a wireless DMX receiver with a wireless DMX-compatible transmitter, the "Unlink" or
"Receive Reset" command must be executed in the menu item "Wireless". The receiver is now
ready to pair and waiting for a pairing request from a transmitter. Start the pairing by selecting
"Link" in the menu of the transmitter and confirming; the pairing now takes place automatically.
Simultaneous or consecutive pairing of several receivers to a transmitter (for example, for master/
slave operation) can also be done in the same manner. A wireless DMX connection is always
maintained until it is disconnected with the reset command in the receiver or the unlink command
in the transmitter, regardless of whether a device has been disconnected from the power supply
in the meantime.
OPERATION
NOTES
Upon switching on the light, the message "Update Wait" is displayed momentarily, followed by
"Welcome to Cameo", the model name and the software version. Thereafter, the motors are reset
(Motor Reset Please Wait). After this process, the fixture is ready for operation and the previously
activated operating mode is launched.
MAIN SCREEN IN DMX OPERATING MODE
In DMX mode, the main screen shows the currently set DMX start address (see illustration). Flash-
ing characters indicate that no DMX signal is present.
SET DMX START ADDRESS (DMX address)
Starting from the main display, press MENU to access the main menu. Now use ⏶ or ⏷ to select
the menu item DMX Address and confirm with ENTER. Use ⏶ or ⏷ to configure the desired
DMX start address and press ENTER to confirm (the highest possible value depends on the select-
ed DMX operating mode).
