NOTES ON PORTABLE OUTDOOR DEVICES
1. Temporary operation! Event equipment is generally only designed for temporary
operation.
2. Continuous operation or permanent structural installation – particularly outdoors –
can impair the function, surfaces, and seals and cause premature material fatigue.
3. Damage to the surface coating can impair the device's corrosion protection. Da-
maged surface coating (for example, scratches) must be promptly repaired using
suitable measures.
PACKAGING CONTENT
Remove the product from the packaging and remove all packaging material.
Please check the completeness and integrity of the delivery, and notify your distribution partner
immediately after purchase if the delivery is not complete or if it is damaged.
The packaging content for the product includes:
X 1 × AZOR
SP2 Compact IP65 Spot Profile Moving Head
®
X 2 × Omega mounting bracket
X 1 × Mains cable
X Safety and compliance information (user manual as a download via QR code)
INTRODUCTION
COMPACT IP65 SPOT PROFILE MOVING HEAD
CLAZORSP2IP
CONTROL FUNCTIONS:
32-channel Basic, 37-channel Standard, 43-channel Extended DMX control
DMX512
Integrated wireless DMX receiver
Master/slave operation
Stand-alone functions
FEATURES:
IP65 protection class. 300 W cold white LED. CMY colour mix. Colour wheel with eight colours
plus open. Gobo wheel with seven rotatable gobos plus open. Zoom, focus, iris, prism and frost
function. Animation wheel. Aperture slider. DMX512. 5-pin DMX connections. 2× Omega moun-
ting bracket included.
The light supports the remote device management (RDM) standard. Remote device management
allows the user to monitor the status and configuration of RDM devices using an RDM-capable
controller, such as the optionally available Cameo UNICON (item number CLIREMOTE). The Cameo
UNICON also allows access to the entire light menu.
11
